500L 1000L 2000L 3000L reverse osmosis RO water purifying system

Model：IF-RO1000

Product:One-stage RO(Reverse Osmosis) water treatment system

Pure Water Production Capacity:2000 litre per hour(25°C)

Input water quality:TDS≤2000PPM

Salt Rejection Rate:≥97%

Recovery Rate(pure water : drain):50~65%

Recommended Working Temp.:5~35°C

Input Power(standard):AC380V / 50Hz

Dimension(standard):4800×700×2050mm

Pre-treatment

Quartz Sand Filter:Φ400×1650mm fiber glass tank with 420KG quartz sand

Or optional Φ400×1650mm(t1.5mm) SUS304 stainless tank

Active Carbon Filter:Φ400×1650mm fiber glass tank with 75KG active carbon

Or optional Φ400×1650mm(t1.5mm) SUS304 stainless tank

Micron (PP Sediment) Filter:SUS304 stainless steel tank with 20inch PP filter×5PCS

Booster Pump:China Lingxiao 4T/37m

Multi-stage Pump:China Nanfang CVF4-16

RO System

Membrane:DOW FILMTEC BLACKISH WATER BW30-4040×8PCS

Optional VONFRON 4040×8PCS

Housing:SUS304 stainless steel 4040 housing×4PCS

Accessories

Piping:U-PVC quick connection

Structure:Full SUS304 stainless steel

Electrical Parts:China CHNT

Or optional SIEMENS / MISTSUBISHI / ABB

Others:Flow metre, TDS metre, pressure metre, electromagnetic valve, etc.

OPTIONAL:Chemical dosing system, UV sterilizer, ozone sterilizer, and built-in RO membrane washing device, softener device
