Automatic high speed rotary 16 cavity bottle blowing machine

The 16-station rotary blow molding machine consists of a rotary main blower, a heating furnace, an automatic feeding device, an electrical control system, and a pneumatic control system. The whole machine has the advantages of high degree of automation, stable and reliable machine performance, high production efficiency and low production cost.

Main feature:

1. Production of 15,000 bottles per hour.

2. Through the touch screen man-machine interface, the whole process of production and each independent area can be fully controlled, and the blowing process of the blowing station can be monitored in real time.

3. Stable infrared heating system and independent heat balance adjustment device, the temperature of the preform is the same when heated, the appearance of the bottle is uniform, and the yield is improved.

4. The heater adopts nine-stage far-infrared temperature control, and each group of heating lamps in the preheating zone and the adjustment zone can be separately controlled and adjusted according to the process requirements, and a real-time temperature monitoring system is provided to ensure the stability and accuracy of the process.

5. Specially designed secondary air blowing system, real-time monitoring of the pressure curve during the molding process of each cavity bottle, providing timely and accurate immediate parameters for process adjustment, greatly facilitating the operator to adjust the process parameters, and the bottle molding quality is stable.

6. According to the different preforms and bottle types of the user, the corresponding heating temperature, blowing time and other process parameters can be set. When the bottle blank type is changed, the preset parameters can be called to produce smoothly.

7. The equipment adopts fully enclosed door and window structure and is equipped with a complete and reliable safety door system to ensure the safety of operators and to maintain the normal operation and safe operation of equipment.
